Description
Typical Applications
- For water supply from wells or reservoirs
- For domestic use, for civil and industrial application
- For Garden use and irrigation
Operating Conditions
- Maximum fluid temperature up to +35°
- Maximum sand content:0.15%
- Minimum well diameter:130mm
Motor and Pump
- Renewable motor
- Single-phase:220V/50Hz
- Three-Phase:380V/50Hz
- Equip with start control box or digital auto-control box
- It’s available to equip with floating switch
- Curve tolerance according to ISO 9906101
- Enclosure Class: X8
- Insulation Class: B
- Voltage: 1x240V
- Speed: 2900rpm
Technical Data
| Model | Motor | Max Particl e Size, mm |
Voltage (V) |
Max Current (A) |
Outlet (“) |
Dimension s (mm) |
Weight (kg) |
||
| KW | HP | H | W | ||||||
| SSWP 600 | 0.55 | 0.75 | 1 | 1×240 | 4.3 | 538 | 538 | 128 | 15 |
| SSWP 10OO | 0.92 | 1.25 | 1×240 | 6.2 | 577 | 577 | 18 | ||
| SSWP 11OO | 1.1 | 1.5 | 1×240 | ||||||
| SSWP 1300 | 1.3 | 1.75 | 1.5 | 1×240 | 7.6 | 577 | 621 | 21 | |
| SSWP 1500 | 1.5 | 2 | 1 | 1×240 | 8.7 | 577 | 621 | 26 | |
