Description
Typical Applications
- Pump clean water with sand content <150g/m³ for diverse applications.
- Extract water efficiently from wells for various agricultural neeSSP.
Utilize the pump for river-based water extraction and distribution purposes. - Support farm irrigation systems, ensuring optimal water supply for crops.
- Provide reliable water supply solutions for various domestic and industrial uses.
- Facilitate efficient water extraction in mining operations for diverse applications.
- Aid in drainage systems within the breeding industry for optimal conditions.
Operating Condition
- Water temperature up to 35℃
- Ambient temperature permissible up to 40℃
- SSP Minimum internal diameter of well: 4″(100mm)
- Maximum Sand Content: 0.25%
- Maximum immersion depth: 80m
| Components | Material |
| Pump body | Stainless steel |
| Pump shaft | Stainless steel |
| Impeller | POM |
| Bearing | C&U |
| Mechanical seal | Ceramic /Graphite, SIC/Graphite or Alloy |
| Coupling and outlet | Brass, Stainless steel |
| Shaft coupling | AISI304 SS |
| Motor shaft | AISI304 SS |
| Oil chamber | Cast iron |
| Model | Motor | Full Load Current (A) | Start Current (A) | Dimensions (mm) | Weight (kg) | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| kW | HP | 1×240 V | 3×415 V | 1×240 V | 3×415 V | P | M | T | ||
| SSP 5/8 | 0.75 | 1 | 6.3 | – | 20 | – | 348 | 398 | 696 | 11.5 |
| SSP 5/12 | 1.1 | 1.5 | 8.5 | 3.6 | 25 | 16 | 444 | 438 | 832 | 13.2 |
| SSP 5/17 | 1.5 | 2 | 10.8 | 4.6 | 35 | 20 | 563 | 515 | 1028 | 16 |
| SSP 5/25 | 2.2 | 3 | 14 | 6.3 | 45 | 33 | 755 | 590 | 1595 | 21.8 |
| SSP 5/33 | 3 | 4 | – | 7.9 | – | 45 | 947 | 605 | 1502 | 27.2 |
| SSP 5/45 | 4 | 5.5 | – | 10.2 | – | 55 | 1115 | 723 | 1788 | 35.4 |
